AS-PL A0438S Generator — FORD

AS-PL A0438S Generator — FORD

1 975,00 kr inkl. moms

STANDARD LINE | Tillverkare: AS-PL | Ersätter: BOSCH

Spänning [ V ] 12
Ström [ A ] 150
A-storlek [ mm ] 43.00
C-storlek [ mm ] 74.00
G [ qty. ] 7
O.D.1 [ mm ] 59.00
Remskiva AFP
D.1 [ mm ] 10.00
D.2 [ mm ] 10.00
D.3 [ mm ] 12.00
E.1 [ mm ] 96.50
E.2 [ mm ] 96.50
L.1 [ mm ] 199.00
Plug PL_2305
COM ID 88
AS-PLSTANDARD LINE
EAN5902129047520
ErsätterBOSCH

📄 Ladda ner datablad med skiss och mått (PDF)

SKU: A0438S Category: Tags: ,

Description

Denna produkt ersätter originaldelar från BOSCH.

Specifikationer

Spänning [ V ] 12
Ström [ A ] 150
A-storlek [ mm ] 43.00
C-storlek [ mm ] 74.00
G [ qty. ] 7
O.D.1 [ mm ] 59.00
Remskiva AFP
D.1 [ mm ] 10.00
D.2 [ mm ] 10.00
D.3 [ mm ] 12.00
E.1 [ mm ] 96.50
E.2 [ mm ] 96.50
L.1 [ mm ] 199.00
Plug PL_2305
COM ID 88

Fordonskompatibilitet

MärkeModellTypMotorHkBränsleÅr
FORD2.2TRANSIT TOURNEO BusCYFA125Diesel2011–2014
FORD2.2TRANSIT TOURNEO BusCYFC125Diesel2011–2014
FORD2.2TRANSIT TOURNEO BusCYFB125Diesel2011–2014
FORD2.2TRANSIT TOURNEO BusCYFD125Diesel2011–2014
FORD2.2 TDCiRANGER (TKE)T22DD0P160Diesel2015–
FORD2.2 TDCiRANGER (TKE)GBVAJPF120Diesel2011–
FORD2.2 TDCiRANGER (TKE)GBVAJQJ150Diesel2011–
FORD2.2 TDCiRANGER (TKE)GBVAJQW125Diesel2011–
FORD2.2 TDCiRANGER (TKE)GBVAJQJ160Diesel2015–
FORD2.2 TDCiRANGER (TKE)ENPF120Diesel2011–
FORD2.2 TDCiRANGER (TKE)ENQJ150Diesel2011–
FORD2.2 TDCiRANGER (TKE)ENQW125Diesel2011–
FORD2.2 TDCiRANGER (TKE)T22DD0P131Diesel2015–
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)PGFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CYFD125Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRFD100Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)QWFA130Diesel2006–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)UHFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CYFA125Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRFA100Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)PGFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CYFC125Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRFC100Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)UHFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRFE100Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)UHFC140Diesel2007–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CYFB125Diesel2011–2014
FORD2.2 TDCiTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRFB100Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRFC100Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYFB125Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRFE100Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYFD125Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRFB100Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYFA125Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)QWFA130Diesel2006–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRFD100Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYFC125Diesel2011–2014
FORD2.2 TDCiTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRFA100Diesel2011–2014
FORD2.2 TDCiTRANSIT TOURNEO BusPGFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT TOURNEO BusUHFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT TOURNEO BusPGFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT TOURNEO BusUHFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT TOURNEO BusUHFC140Diesel2007–2014
FORD2.2 TDCiTRANSIT TOURNEO BusQWFA131Diesel2006–2014
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)CYF5125Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)DRF5100Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)USF6125Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)DRFG100Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)CY14125Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)CYFG125Diesel2013–2018
FORD2.2 TDCiTRANSIT V363 Platform/Chassis (FED, FFD)DRFF100Diesel2013–2018
FORD2.2 TDCiTRANSIT Van (FA_ _)DRFA100Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)PGFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)CYFC125Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)DRFC100Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)UHFB140Diesel2007–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)PGFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)DRFE100Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)QWFA130Diesel2006–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)CYFB125Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)DRFB100Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)UHFA140Diesel2007–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)CYFD125Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)CYFA125Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)DRFD100Diesel2011–2014
FORD2.2 TDCiTRANSIT Van (FA_ _)UHFC140Diesel2007–2014
FORD2.2 TDCi 4x4RANGER (TKE)ENQJ150Diesel2011–
FORD2.2 TDCi 4x4RANGER (TKE)T22DD0P160Diesel2015–
FORD2.2 TDCi 4x4RANGER (TKE)T22DD0P131Diesel2015–
FORD2.2 TDCi 4x4RANGER (TKE)GBVAJQW125Diesel2011–
FORD2.2 TDCi 4x4RANGER (TKE)GBVAJQJ160Diesel2015–
FORD2.2 TDCi 4x4RANGER (TKE)GBVAJQJ150Diesel2011–
FORD2.2 TDCi 4x4RANGER (TKE)ENQW125Diesel2011–
FORD2.2 TDCi 4x4TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYRC125Diesel2011–2014
FORD2.2 TDCi 4x4TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYRB125Diesel2011–2014
FORD2.2 TDCi 4x4TRANSIT V363 Bus (FAD, FBD)CYR5125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Bus (FAD, FBD)CY24125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Platform/Chassis (FED, FFD)CY24125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Platform/Chassis (FED, FFD)CVR5155Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Platform/Chassis (FED, FFD)CV24155Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Platform/Chassis (FED, FFD)CYR5125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Van (FCD, FDD)CY24125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Van (FCD, FDD)CVR5155Diesel2015–2018
FORD2.2 TDCi 4x4TRANSIT V363 Van (FCD, FDD)CYR5125Diesel2013–2018
FORD2.2 TDCi 4x4TRANSIT V363 Van (FCD, FDD)CV24155Diesel2015–2018
FORD2.2 TDCi 4x4TRANSIT Van (FA_ _)CYRC125Diesel2011–2014
FORD2.2 TDCi 4x4TRANSIT Van (FA_ _)CYRB125Diesel2011–2014
FORD2.2 TDCi All-wheel DriveTRANSIT V363 Bus (FAD, FBD)CVR5155Diesel2015–2018
FORD2.2 TDCi All-wheel DriveTRANSIT V363 Bus (FAD, FBD)CV24155Diesel2015–2018
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRRB100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)USRA135Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CVRC155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)CYRA125Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRRA100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)DRRC100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)USRB135Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CVRA155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CYRA125Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRRC100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CVRC155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRRB100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)CVRB155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)DRRA100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)UHR5135Diesel2013–
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)CV24155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)UYR6155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)USR6125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)CVR5155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)DRR5100Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Bus (FAD, FBD)CYR5125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)UYR6155Diesel2013–
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)CV24155Diesel2013–
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)CYR5155Diesel2013–
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)USR6125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)CYR5125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)CYR5125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)DRR5100Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Platform/Chassis (FED, FFD)UHR5135Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)CYR5125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)CV24155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)UYR6155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)DRR5100Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)USR6125Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT V363 Van (FCD, FDD)CVR5155Diesel2013–2018
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)CVRA155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)DRRA100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)CVRC155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)DRRC100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)USRB136Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)CYRA125Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)CVRB155Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)DRRB100Diesel2011–2014
FORD2.2 TDCi RWDTRANSIT Van (FA_ _)USRA136Diesel2011–2014
FORD3.2 TDCi 4x4RANGER (TKE)SA2S200Diesel2011–
FORD3.2 TDCi 4x4RANGER (TKE)SAFA200Diesel2011–
FORD3.2 TDCi 4x4RANGER (TKE)ENSA200Diesel2011–
FORD3.2 TDCi 4x4RANGER (TKE)SA2R200Diesel2011–
FORD3.2 TDCi 4x4RANGER (TKE)SA2W200Diesel2011–
FORD3.2 TDCi 4x4RANGER (TKE)P5-AT200Diesel2011–
