AS-PL S0012 Startmotor — IVECO

AS-PL S0012 Startmotor — IVECO

2 283,00 kr inkl. moms

STANDARD LINE | Tillverkare: AS-PL | Ersätter: BOSCH

Spänning [ V ] 24
Effekt [ kW ] 6.60
Startmotors rotation CW
A-storlek [ mm ] 115.00
B-storlek [ mm ] 21.00
Antal kuggar [ qty. ] 11
Antal kuggar (passar in) [ qty. ] 11
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 407.00
O.1 [ mm ] 126.50
O.2 [ mm ] 126.50
O.3 [ mm ] 126.50
C.1 [ mm ] 15.50
C.2 [ mm ] 15.50
C.3 [ mm ] 15.50
Oil sealed Yes
AS-PLSTANDARD LINE
EAN5901259418491
ErsätterBOSCH
OE-nummer0001417064

📄 Ladda ner datablad med skiss och mått (PDF)

SKU: S0012 Category: Tags: ,

Description

Denna produkt ersätter originaldelar från BOSCH.

OE-nummer: 0001417064

Specifikationer

Spänning [ V ] 24
Effekt [ kW ] 6.60
Startmotors rotation CW
A-storlek [ mm ] 115.00
B-storlek [ mm ] 21.00
Antal kuggar [ qty. ] 11
Antal kuggar (passar in) [ qty. ] 11
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 407.00
O.1 [ mm ] 126.50
O.2 [ mm ] 126.50
O.3 [ mm ] 126.50
C.1 [ mm ] 15.50
C.2 [ mm ] 15.50
C.3 [ mm ] 15.50
Oil sealed Yes

Fordonskompatibilitet

MärkeModellTypMotorHkBränsleÅr
IVECO180 E 42EUROTECH MP8210.42L.4004201992–1993
IVECO190 E 42, 190 E 42 /PEUROTECH MP8210.42L.4004201993–
IVECO240 E 42EUROTECH MP8210.42L.4004201992–
IVECO240 E 42EUROTECH MP8210.42L.4004201992–
IVECO260 E 42EUROTECH MP8210.42L.4004201994–
IVECO400 E 42 T, 440 E 42 T, 440 E 42 T/PEUROTECH MP8210.42L.4004201992–
IVECO400 E 42 T, 440 E 42 T, 440 E 42 T/PEUROTECH MP8210.42L(TCA)4201992–
IVECO440 E 42 TZEUROTECH MP8210.42L.4004201993–
IVECOLD 190 E 42, LD 190 E 42 PEUROSTAR8210.42L(TCA)4201993–2002
IVECOLD 190 E 42, LD 190 E 42 PEUROSTAR8210.42L.4004201993–2002
IVECOLD 190 E 47EUROSTAR8210.42M.TCA4691993–2002
IVECOLD 240 E 42 FS, LD 240 E 42 PSEUROSTAR8210.42L.4004201993–2002
IVECOLD 240 E 42 FS, LD 240 E 42 PSEUROSTAR8210.42L.4004201993–2002
IVECOLD 240 E 42 FS, LD 240 E 42 PSEUROSTAR8210.42L(TCA)4201993–2002
IVECOLD 240 E 42 FS, LD 240 E 42 PSEUROSTAR8210.42L(TCA)4201993–2002
IVECOLD 240 E 47 PSEUROSTAR8210.42M.TCA4691993–2002
IVECOLD 240 E 47 PSEUROSTAR8210.42M.TCA4691993–2002
IVECOLD 260 E 42 PEUROSTAR8210.42L.4201993–2002
IVECOLD 260 E 47EUROSTAR8210.42M.TCA4691993–2002
IVECOLD 400 E 42 TX/P,LD 440 E 42 TX/PEUROSTAR8210.42L.4201993–2002
IVECOLD 440 E 42 T/PEUROSTAR8210.42L.4201993–2002
IVECOLD 440 E 42 T/PEUROSTAR8210.42L(TCA)4201993–2002
IVECOLD 440 E 42 TZEUROSTAR8210.42L.4201993–2002
IVECOLD 440 E 47 T/PEUROSTAR8210.42M.TCA4691993–2002
IVECOLD 440 E 47 TZEUROSTAR8210.42M.TCA4691993–2002
IVECOMP 190 E 37 HEUROTRAKKER8210.42K.3701993–2004
IVECOMP 190 E 37 HEUROTRAKKER8210.42K(TCA)3702000–2004
IVECOMP 190 E 37 WEUROTRAKKER8210.42K.3701993–2004
IVECOMP 190 E 37 WEUROTRAKKER8210.42K(TCA)3701999–2004
IVECOMP 190 E 42 HEUROTRAKKER8210.42L(TCA)4201999–2004
IVECOMP 190 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 190 E 42 HEUROTRAKKER8210.42L.4201999–2004
IVECOMP 190 E 42 WEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 190 E 42 WEUROTRAKKER8210.42L.4201993–2004
IVECOMP 260 E 37 HEUROTRAKKER8210.42K.3701993–2004
IVECOMP 260 E 37 WEUROTRAKKER8210.42K(TCA)3701999–2004
IVECOMP 260 E 37 WEUROTRAKKER8210.42K.3701993–2004
IVECOMP 260 E 37 WEUROTRAKKER8210.42K.3701999–2004
IVECOMP 260 E 42 HEUROTRAKKER8210.42L(TCA)4201999–2004
IVECOMP 260 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 260 E 42 WEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 260 E 42 WEUROTRAKKER8210.42L.4201993–2004
IVECOMP 260 E 47 HEUROTRAKKER8210.42M.TCA4691999–2004
IVECOMP 340 E 37 HEUROTRAKKER8210.42K.3701999–2004
IVECOMP 340 E 37 HEUROTRAKKER8210.42K(TCA)3701999–2004
IVECOMP 340 E 37 HEUROTRAKKER8210.42K.3701993–2004
IVECOMP 340 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 340 E 42 HEUROTRAKKER8210.42L.4201999–2004
IVECOMP 340 E 42 HEUROTRAKKER8210.42L(TCA)4201999–2004
IVECOMP 380 E 37 HEUROTRAKKER8210.42K(TCA)3701998–2004
IVECOMP 380 E 37 HEUROTRAKKER8210.42K.3701998–2004
IVECOMP 380 E 37 HEUROTRAKKER8210.42K.3701993–2004
IVECOMP 380 E 37 WEUROTRAKKER8210.42K(TCA)3701999–2004
IVECOMP 380 E 37 WEUROTRAKKER8210.42K.3701993–2004
IVECOMP 380 E 37 WEUROTRAKKER8210.42K.3701999–2004
IVECOMP 380 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 380 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 380 E 42 HEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 380 E 42 WEUROTRAKKER8210.42L(TCA)4201999–2004
IVECOMP 380 E 42 WEUROTRAKKER8210.42L.4201993–2004
IVECOMP 380 E 42 WEUROTRAKKER8210.42L.4201999–2004
IVECOMP 380 E 47 HEUROTRAKKER8210.42M.TCA4701999–2004
IVECOMP 400 E 37 HTEUROTRAKKER8210.42K.3701993–2004
IVECOMP 400 E 37 HTEUROTRAKKER8210.42K(TCA)3701993–2004
IVECOMP 400 E 37 WTEUROTRAKKER8210.42K.3701993–2004
IVECOMP 400 E 37 WTEUROTRAKKER8210.42K(TCA)3701993–2004
IVECOMP 400 E 42 HTEUROTRAKKER8210.42L.4201993–2004
IVECOMP 400 E 42 HTEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 400 E 42 WTEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 400 E 42 WTEUROTRAKKER8210.42L.4201993–2004
IVECOMP 410 E 37 HEUROTRAKKER8210.42K(TCA)3701999–2004
IVECOMP 410 E 37 HEUROTRAKKER8210.42K.3701993–2004
IVECOMP 410 E 42 HEUROTRAKKER8210.42L.4201993–2004
IVECOMP 410 E 42 HEUROTRAKKER8210.42L(TCA)4201999–2004
IVECOMP 410 E 42 WEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 410 E 42 WEUROTRAKKER8210.42L.4201993–2004
IVECOMP 440 E 37 HTEUROTRAKKER8210.42K(TCA)3701993–2004
IVECOMP 440 E 37 HTEUROTRAKKER8210.42K.3701993–2004
IVECOMP 440 E 42 HTEUROTRAKKER8210.42L.4201993–2004
IVECOMP 440 E 42 HTEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 720 E 37 HTEUROTRAKKER8210.42K(TCA)3701993–2004
IVECOMP 720 E 37 HTEUROTRAKKER8210.42K.3701993–2004
IVECOMP 720 E 37 WTEUROTRAKKER8210.42K.3701993–2004
IVECOMP 720 E 37 WTEUROTRAKKER8210.42K(TCA)3701993–2004
IVECOMP 720 E 42 HTEUROTRAKKER8210.42L.4201993–2004
IVECOMP 720 E 42 HTEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 720 E 42 WTEUROTRAKKER8210.42L.4201993–2004
IVECOMP 720 E 42 WTEUROTRAKKER8210.42L(TCA)4201993–2004
IVECOMP 720 E 47 HTEUROTRAKKER8210.42M.TCA4691993–2004
