AS-PL S0477 Startmotor — VW, SEAT, SKODA

AS-PL S0477 Startmotor — VW, SEAT, SKODA

1 015,00 kr inkl. moms

STANDARD LINE | Tillverkare: AS-PL | Ersätter: BOSCH

Spänning [ V ] 12
Effekt [ kW ] 1.10
Startmotors rotation ACW
A-storlek [ mm ] 79.00
B-storlek [ mm ] 52.00
Antal kuggar [ qty. ] 13
Antal kuggar (passar in) [ qty. ] 13
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 229.00
O.1 [ mm ] 18.00
O.2 [ mm ] 112.00
O.3 [ mm ] 127.00
AS-PLSTANDARD LINE
EAN5901259484656
ErsätterBOSCH
OE-nummer0001179503

📄 Ladda ner datablad med skiss och mått (PDF)

SKU: S0477 Category: Tags: ,

Description

Denna produkt ersätter originaldelar från BOSCH.

OE-nummer: 0001179503

Specifikationer

Spänning [ V ] 12
Effekt [ kW ] 1.10
Startmotors rotation ACW
A-storlek [ mm ] 79.00
B-storlek [ mm ] 52.00
Antal kuggar [ qty. ] 13
Antal kuggar (passar in) [ qty. ] 13
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 229.00
O.1 [ mm ] 18.00
O.2 [ mm ] 112.00
O.3 [ mm ] 127.00

Fordonskompatibilitet

MärkeModellTypMotorHkBränsleÅr
AUDI1.0 TFSIQ2 (GAB, GAG)CHZJ115Petrol2016–2020
AUDI1.4 TFSIA3 (8V1, 8VK)CXSB125Petrol2014–2016
AUDI1.4 TFSIA3 (8V1, 8VK)CPTA140Petrol2013–2016
AUDI1.4 TFSIA3 (8V1, 8VK)CXSA122Petrol2012–2014
AUDI1.4 TFSIA3 (8V1, 8VK)CZCA125Petrol2014–2016
AUDI1.4 TFSIA3 (8V1, 8VK)CMBA122Petrol2012–2014
AUDI1.4 TFSIA3 Convertible (8V7, 8VE)CPTA140Petrol2013–2014
AUDI1.4 TFSIA3 Convertible (8V7, 8VE)CZCC115Petrol2016–2020
AUDI1.4 TFSIA3 Convertible (8V7, 8VE)CXSB125Petrol2014–2016
AUDI1.4 TFSIA3 Convertible (8V7, 8VE)CZCA125Petrol2014–2016
AUDI1.4 TFSIA3 Limousine (8VS, 8VM)CPTA140Petrol2013–2016
AUDI1.4 TFSIA3 Limousine (8VS, 8VM)CXSA122Petrol2013–2020
AUDI1.4 TFSIA3 Limousine (8VS, 8VM)CZCA125Petrol2013–2016
AUDI1.4 TFSIA3 Limousine (8VS, 8VM)CXSB125Petrol2013–2016
AUDI1.4 TFSIA3 Sportback (8VA, 8VF)CPTA140Petrol2013–2014
AUDI1.4 TFSIA3 Sportback (8VA, 8VF)CXSA122Petrol2012–2020
AUDI1.4 TFSIA3 Sportback (8VA, 8VF)CXSB125Petrol2014–2016
AUDI1.4 TFSIA3 Sportback (8VA, 8VF)CMBA122Petrol2012–2020
AUDI1.4 TFSIA3 Sportback (8VA, 8VF)CZCA125Petrol2014–2016
AUDI1.4 TFSIQ2 (GAB, GAG)CZEA150Petrol2016–
AUDI1.4 TFSI g-tronA3 Sportback (8VA, 8VF)CPWA110Petrol/Compressed Natural Gas (CNG)2013–2020
AUDI1.4 TSIA3 (8V1, 8VK)CZEA150Petrol2014–2017
AUDI1.4 TSIA3 Convertible (8V7, 8VE)CZEA150Petrol2014–2020
AUDI1.4 TSIA3 Limousine (8VS, 8VM)CZEA150Petrol2014–2020
AUDI1.4 TSIA3 Sportback (8VA, 8VF)CZEA150Petrol2014–2020
AUDI1.8 TFSIA3 (8V1, 8VK)CJSA180Petrol2012–2016
AUDI1.8 TFSIA3 Convertible (8V7, 8VE)CJSB180Petrol2013–2016
AUDI1.8 TFSIA3 Convertible (8V7, 8VE)CJSA180Petrol2013–2016
AUDI1.8 TFSIA3 Limousine (8VS, 8VM)CJSB180Petrol2013–2016
AUDI1.8 TFSIA3 Limousine (8VS, 8VM)CJSA180Petrol2013–2016
AUDI1.8 TFSIA3 Sportback (8VA, 8VF)CJSB180Petrol2012–2016
AUDI1.8 TFSIA3 Sportback (8VA, 8VF)CJSA180Petrol2012–2016
AUDI1.8 TFSI quattroA3 (8V1, 8VK)CJSB180Petrol2012–2016
AUDI1.8 TFSI quattroA3 Convertible (8V7, 8VE)CJSB180Petrol2014–2016
AUDI1.8 TFSI quattroA3 Limousine (8VS, 8VM)CJSB180Petrol2013–2016
AUDI1.8 TFSI quattroA3 Sportback (8VA, 8VF)CJSB180Petrol2013–2016
AUDI30 TDIQ2 (GAB, GAG)DGTE115Diesel2018–2020
SEAT1.0 TGIIBIZA V (KJ1, KJG)DBYA90Petrol/Compressed Natural Gas (CNG)2017–
SEAT1.0 TGiARONA (KJ7, KJP)DBYA90Petrol/Compressed Natural Gas (CNG)2018–
SEAT1.0 TSIARONA (KJ7, KJP)DUSA115Petrol2017–
SEAT1.0 TSIARONA (KJ7, KJP)DLAA110Petrol2020–
SEAT1.0 TSIARONA (KJ7, KJP)CHZJ115Petrol2017–
SEAT1.0 TSIARONA (KJ7, KJP)DKRF115Petrol2017–
SEAT1.0 TSIARONA (KJ7, KJP)DXUA115Petrol2017–
SEAT1.0 TSIARONA (KJ7, KJP)DKJA115Petrol2017–
SEAT1.0 TSIATECA (KH7, KHP)CHZJ115Petrol2016–
SEAT1.0 TSIATECA (KH7, KHP)DUSA115Petrol2016–
SEAT1.0 TSIATECA (KH7, KHP)DKRF115Petrol2016–
SEAT1.0 TSIIBIZA V (KJ1, KJG)DKRF115Petrol2017–
SEAT1.0 TSIIBIZA V (KJ1, KJG)DKJA115Petrol2017–
SEAT1.0 TSIIBIZA V (KJ1, KJG)DUSA115Petrol2017–
SEAT1.0 TSIIBIZA V (KJ1, KJG)CHZJ115Petrol2017–
SEAT1.0 TSILEON (5F1)DKRF115Petrol2015–2020
SEAT1.0 TSILEON (5F1)CHZD115Petrol2015–2020
SEAT1.0 TSILEON SC (5F5)CHZD115Petrol2015–2018
SEAT1.0 TSILEON ST (5F8)DKRF115Petrol2015–2020
SEAT1.0 TSILEON ST (5F8)CHZD115Petrol2015–2020
SEAT1.0 TSiLEON (5F1)DKLB86Petrol2018–2020
SEAT1.0 TSiLEON ST (5F8)DKLB86Petrol2018–2020
SEAT1.4 TGILEON (5F1)CPWA110Petrol/Compressed Natural Gas (CNG)2013–2018
SEAT1.4 TGILEON ST (5F8)CPWA110Petrol/Compressed Natural Gas (CNG)2013–2018
SEAT1.4 TSIATECA (KH7, KHP)CZEA150Petrol2016–
SEAT1.4 TSIATECA (KH7, KHP)DJKA150Petrol2016–
SEAT1.4 TSILEON (5F1)CZDA150Petrol2014–2020
SEAT1.4 TSILEON (5F1)CPTA140Petrol2012–2020
SEAT1.4 TSILEON (5F1)CMBA122Petrol2012–2016
SEAT1.4 TSILEON (5F1)CZCA125Petrol2014–2020
SEAT1.4 TSILEON (5F1)CHPA140Petrol2012–2020
SEAT1.4 TSILEON (5F1)CZEA150Petrol2014–2020
SEAT1.4 TSILEON (5F1)CXSA122Petrol2012–2016
SEAT1.4 TSILEON Hatchback Van (5F1)CMBA122Petrol2012–2016
SEAT1.4 TSILEON Hatchback Van (5F1)CHPA140Petrol2012–2016
SEAT1.4 TSILEON Hatchback Van (5F1)CZEA150Petrol2014–2020
SEAT1.4 TSILEON Hatchback Van (5F1)CXSA122Petrol2012–2016
SEAT1.4 TSILEON Hatchback Van (5F1)CPTA140Petrol2012–2016
SEAT1.4 TSILEON SC (5F5)CPTA140Petrol2013–2016
SEAT1.4 TSILEON SC (5F5)CZCA125Petrol2014–2018
SEAT1.4 TSILEON SC (5F5)CMBA122Petrol2013–2015
SEAT1.4 TSILEON SC (5F5)CHPA140Petrol2013–2016
SEAT1.4 TSILEON SC (5F5)CZEA150Petrol2014–2018
SEAT1.4 TSILEON SC (5F5)CXSA122Petrol2013–2015
SEAT1.4 TSILEON ST (5F8)CMBA122Petrol2012–2015
SEAT1.4 TSILEON ST (5F8)CZEA150Petrol2014–2020
SEAT1.4 TSILEON ST (5F8)CHPA140Petrol2013–2020
SEAT1.4 TSILEON ST (5F8)CZCA125Petrol2014–2018
SEAT1.4 TSILEON ST (5F8)CXSA122Petrol2012–2015
SEAT1.4 TSILEON ST (5F8)CPTA140Petrol2013–2020
SEAT1.4 TSILEON ST Estate Van (5F8)CZEA150Petrol2014–2020
SEAT1.4 TSILEON ST Estate Van (5F8)CZDA150Petrol2014–2020
SEAT1.4 TSITOLEDO IV (KG3)CZCA125Petrol2015–2019
SEAT1.4 TSI 4DriveATECA (KH7, KHP)CZEA150Petrol2016–
SEAT1.8 TFSILEON Hatchback Van (5F1)CJSA180Petrol2013–2018
SEAT1.8 TFSILEON ST Estate Van (5F8)CJSA180Petrol2013–2018
SEAT1.8 TSILEON (5F1)CJSA180Petrol2013–2018
SEAT1.8 TSILEON SC (5F5)CJSA180Petrol2013–2018
SEAT1.8 TSILEON ST (5F8)CJSA180Petrol2013–2018
SKODA1.0 TGI CNGKAMIQ (NW4)DBYA90Petrol/Compressed Natural Gas (CNG)2019–
SKODA1.0 TGI CNGSCALA (NW1)DBYA90Petrol/Compressed Natural Gas (CNG)2019–
SKODA1.0 TSIKAMIQ (NW4)DXUA115Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DKJA115Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DKLA95Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DUSA115Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DUSB95Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DKRF115Petrol2019–
SKODA1.0 TSIKAMIQ (NW4)DLAC95Petrol2019–
SKODA1.0 TSIKAROQ (NU7, ND7)DKRF115Petrol2017–
SKODA1.0 TSIKAROQ (NU7, ND7)CHZJ115Petrol2017–
SKODA1.0 TSIKAROQ (NU7, ND7)DUSA115Petrol2017–
SKODA1.0 TSIOCTAVIA III (5E3, NL3, NR3)DKRF115Petrol2016–2020
SKODA1.0 TSIOCTAVIA III (5E3, NL3, NR3)DKRA115Petrol2016–2020
SKODA1.0 TSIOCTAVIA III (5E3, NL3, NR3)CHZD115Petrol2016–2020
SKODA1.0 TSIOCTAVIA III Combi (5E5, 5E6)DKRA115Petrol2016–2020
SKODA1.0 TSIOCTAVIA III Combi (5E5, 5E6)CHZD115Petrol2016–2020
SKODA1.0 TSIOCTAVIA III Combi (5E5, 5E6)DKRF115Petrol2016–2020
SKODA1.0 TSISCALA (NW1)DLAC95Petrol2019–
SKODA1.0 TSISCALA (NW1)DKJA116Petrol2019–
SKODA1.0 TSISCALA (NW1)DUSA116Petrol2019–
SKODA1.0 TSISCALA (NW1)DKLA95Petrol2019–
SKODA1.0 TSISCALA (NW1)DUSB95Petrol2019–
SKODA1.0 TSISCALA (NW1)DKRF116Petrol2019–
SKODA1.0 TSISCALA (NW1)DXUA116Petrol2019–
SKODA1.2 TSIYETI (5L)CYVB110Petrol2015–2017
SKODA1.4 TSIKAROQ (NU7, ND7)DJKA150Petrol2017–
SKODA1.4 TSIKAROQ (NU7, ND7)CZEA150Petrol2017–
SKODA1.4 TSIOCTAVIA III (5E3, NL3, NR3)CZDA150Petrol2014–2020
SKODA1.4 TSIOCTAVIA III (5E3, NL3, NR3)CHPA140Petrol2012–2017
SKODA1.4 TSIOCTAVIA III (5E3, NL3, NR3)CHPB150Petrol2014–2020
SKODA1.4 TSIOCTAVIA III Combi (5E5, 5E6)CHPA140Petrol2012–2017
SKODA1.4 TSIOCTAVIA III Combi (5E5, 5E6)CHPB150Petrol2014–2020
SKODA1.4 TSIOCTAVIA III Combi (5E5, 5E6)CZDA150Petrol2014–2020
SKODA1.4 TSIOCTAVIA IV (NX3, NN3, PV3)DJKA150Petrol2021–
SKODA1.4 TSIOCTAVIA IV Combi (NX5, PV5)DJKA150Petrol2020–
SKODA1.4 TSIRAPID (NH3, NK3, NK6)CZCA125Petrol2015–2022
SKODA1.4 TSIRAPID Spaceback (NH1)CZCA125Petrol2015–2019
SKODA1.4 TSISUPERB III (3V3)CZDA150Petrol2015–
SKODA1.4 TSISUPERB III (3V3)CZCA125Petrol2015–
SKODA1.4 TSISUPERB III (3V3)CZEA150Petrol2015–
SKODA1.4 TSISUPERB III Estate (3V5)CZCA125Petrol2015–
SKODA1.4 TSISUPERB III Estate (3V5)CZEA150Petrol2015–
SKODA1.4 TSISUPERB III Estate (3V5)CZDA150Petrol2015–
SKODA1.4 TSIYETI (5L)CZCA125Petrol2015–2017
SKODA1.4 TSI 4x4SUPERB III (3V3)CZEA150Petrol2015–
SKODA1.4 TSI 4x4SUPERB III Estate (3V5)CZEA150Petrol2015–
SKODA1.4 TSI G-TECOCTAVIA III (5E3, NL3, NR3)CPWA110Petrol/Compressed Natural Gas (CNG)2013–2017
SKODA1.4 TSI G-TECOCTAVIA III Combi (5E5, 5E6)CPWA110Petrol/Compressed Natural Gas (CNG)2012–2017
SKODA1.8 TSIOCTAVIA III (5E3, NL3, NR3)CJSA180Petrol2012–2020
SKODA1.8 TSIOCTAVIA III Combi (5E5, 5E6)CJSB180Petrol2012–2020
SKODA1.8 TSIOCTAVIA III Combi (5E5, 5E6)CJSA180Petrol2012–2020
SKODA1.8 TSI 4x4OCTAVIA III (5E3, NL3, NR3)CJSB180Petrol2014–2020
SKODA1.8 TSI 4x4OCTAVIA III Combi (5E5, 5E6)CJSB180Petrol2012–2017
VW1.0 TSICADDY ALLTRACK IV Box Body/MPV (SAA)CHZG102Petrol2015–
VW1.0 TSICADDY ALLTRACK IV MPV (SAB)DKRD84Petrol2018–2019
VW1.0 TSICADDY ALLTRACK IV MPV (SAB)CHZG102Petrol2015–
VW1.0 TSICADDY IV Box Body/MPV (SAA, SAH)DKRE102Petrol2015–2020
VW1.0 TSICADDY IV Box Body/MPV (SAA, SAH)CHZG102Petrol2015–2020
VW1.0 TSICADDY IV MPV (SAB, SAJ)CHZG102Petrol2015–2020
VW1.0 TSICADDY IV MPV (SAB, SAJ)DKRD84Petrol2018–2019
VW1.0 TSICADDY IV MPV (SAB, SAJ)DKRE102Petrol2015–2020
VW1.0 TSIGOLF SPORTSVAN VII (AM1, AN1)DKLB86Petrol2017–2019
VW1.0 TSIGOLF SPORTSVAN VII (AM1, AN1)DKRF115Petrol2015–2020
VW1.0 TSIGOLF SPORTSVAN VII (AM1, AN1)CHZK86Petrol2017–2019
VW1.0 TSIGOLF SPORTSVAN VII (AM1, AN1)CHZC110Petrol2017–2018
VW1.0 TSIGOLF SPORTSVAN VII (AM1, AN1)CHZD115Petrol2015–2020
VW1.0 TSIGOLF VII (5G1, BQ1, BE1, BE2)CHZD115Petrol2015–2020
VW1.0 TSIGOLF VII (5G1, BQ1, BE1, BE2)CHZC110Petrol2016–2020
VW1.0 TSIGOLF VII (5G1, BQ1, BE1, BE2)CHZK86Petrol2017–2019
VW1.0 TSIGOLF VII (5G1, BQ1, BE1, BE2)DKRF115Petrol2015–2020
VW1.0 TSIGOLF VII (5G1, BQ1, BE1, BE2)DKLB86Petrol2017–2019
VW1.0 TSIGOLF VII Variant (BA5, BV5)DKLB86Petrol2017–2019
VW1.0 TSIGOLF VII Variant (BA5, BV5)CHZD115Petrol2015–2020
VW1.0 TSIGOLF VII Variant (BA5, BV5)CHZK86Petrol2017–2019
VW1.0 TSIGOLF VII Variant (BA5, BV5)CHZC110Petrol2016–2020
VW1.0 TSIGOLF VII Variant (BA5, BV5)DKRF115Petrol2015–2020
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DXTA95Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DUSA116Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DKLA95Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)CHZJ116Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DUSB95Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DKRF116Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)CHZL95Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DXUA116Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DLAC95Petrol2017–
VW1.0 TSIPOLO VI (AW1, BZ1, AE1)DKJA116Petrol2017–
VW1.0 TSIT-CROSS (C11, D31)DLAA110Petrol2020–
VW1.0 TSIT-ROC (A11, D11)CHZJ115Petrol2017–
VW1.0 TSIT-ROC (A11, D11)DUSA115Petrol2017–
VW1.0 TSIT-ROC (A11, D11)DKRF115Petrol2017–
VW1.0 TSIT-ROC Convertible (AC7, AC8)DUSA116Petrol2019–
VW1.0 TSIT-ROC Convertible (AC7, AC8)DKRF116Petrol2019–
VW1.0 TSITOURAN (5T1)DKRB116Petrol2018–
VW1.0 TSiT-CROSS (C11, D31)DHSC116Petrol2018–
VW1.0 TSiT-CROSS (C11, D31)DKRF116Petrol2018–
VW1.0 TSiT-CROSS (C11, D31)DKJA116Petrol2018–
VW1.0 TSiT-CROSS (C11, D31)DUSA116Petrol2018–
VW1.4 TGI CNGCADDY ALLTRACK IV Box Body/MPV (SAA)CPWA110Petrol/Compressed Natural Gas (CNG)2015–
VW1.4 TGI CNGCADDY ALLTRACK IV MPV (SAB)CPWA110Petrol/Compressed Natural Gas (CNG)2015–
VW1.4 TGI CNGCADDY IV Box Body/MPV (SAA, SAH)CPWA110Petrol/Compressed Natural Gas (CNG)2015–2020
VW1.4 TGI CNGCADDY IV MPV (SAB, SAJ)CPWA110Petrol/Compressed Natural Gas (CNG)2015–2020
VW1.4 TGI CNGGOLF VII (5G1, BQ1, BE1, BE2)CZBA110Petrol/Compressed Natural Gas (CNG)2013–2018
VW1.4 TGI CNGGOLF VII (5G1, BQ1, BE1, BE2)CPWA110Petrol/Compressed Natural Gas (CNG)2013–2018

Visar 200 av 266 fordon

Reviews

There are no reviews yet.

Be the first to review “AS-PL S0477 Startmotor — VW, SEAT, SKODA”

Your email address will not be published. Required fields are marked *

Related products
