AS-PL S5022SR Startmotor — RENAULT TRUCKS, IRISBUS

AS-PL S5022SR Startmotor — RENAULT TRUCKS, IRISBUS

1 653,00 kr inkl. moms

STANDARD LINE | Tillverkare: AS-PL | Ersätter: MITSUBISHI

Spänning [ V ] 24
Effekt [ kW ] 6.00
Startmotors rotation CW
A-storlek [ mm ] 89.00
B-storlek [ mm ] 41.00
Antal kuggar [ qty. ] 12
Antal kuggar (passar in) [ qty. ] 12
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 351.00
O.1 [ mm ] 127.00
O.2 [ mm ] 90.00
O.3 [ mm ] 90.00
C.1 [ mm ] 13.50
C.2 [ mm ] 13.50
C.3 [ mm ] 13.50
AS-PLSTANDARD LINE
EAN5902129221319
ErsätterMITSUBISHI

📄 Ladda ner datablad med skiss och mått (PDF)

SKU: S5022SR Category: Tags: ,

Description

Denna produkt ersätter originaldelar från MITSUBISHI.

Specifikationer

Spänning [ V ] 24
Effekt [ kW ] 6.00
Startmotors rotation CW
A-storlek [ mm ] 89.00
B-storlek [ mm ] 41.00
Antal kuggar [ qty. ] 12
Antal kuggar (passar in) [ qty. ] 12
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 351.00
O.1 [ mm ] 127.00
O.2 [ mm ] 90.00
O.3 [ mm ] 90.00
C.1 [ mm ] 13.50
C.2 [ mm ] 13.50
C.3 [ mm ] 13.50

Fordonskompatibilitet

MärkeModellTypMotorHkBränsleÅr
IRISBUS7.8Agora L02003–2005
IRISBUS7.8Agora L02003–
IRISBUS7.8Agora S02003–
IRISBUS7.8Agora S02003–2005
RENAULT TRUCKS260.18KERAXMIDR06.20.45C/42561997–
RENAULT TRUCKS260.18/BKERAXMIDR06.20.45C/42561997–
RENAULT TRUCKS270.18KERAXdCi11-2702652001–
RENAULT TRUCKS270.18KERAXdCi11-2702652001–
RENAULT TRUCKS300.18/BKERAXMIDR06.20.45D/412981997–
RENAULT TRUCKS300.26/A,300.26/BKERAXMIDR06.20.45D/412981997–
RENAULT TRUCKS300.26/A,300.26/BKERAXMIDR06.20.45D/412981997–
RENAULT TRUCKS300.26/BKERAXMIDR06.20.45D/412981997–
RENAULT TRUCKS320.18KERAXdCi11G3132001–
RENAULT TRUCKS320.18KERAXdCi11G3132001–
RENAULT TRUCKS320.26KERAXdCi11G3132001–
RENAULT TRUCKS320.26KERAXdCi11G3132001–
RENAULT TRUCKS320.26KERAXdCi11G3132001–
RENAULT TRUCKS340.18KERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.18/BKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.26/A,340.26/BKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.26/A,340.26/BKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.26/BKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.32/AKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS340.32/AKERAXMIDR06.20.45E/413391997–
RENAULT TRUCKS350.34KERAXMIDR06.23.56A/33472003–
RENAULT TRUCKS370.18KERAXdCi11E3622001–
RENAULT TRUCKS370.18KERAXdCi11E3622001–
RENAULT TRUCKS370.18KERAXdCi11E3622001–
RENAULT TRUCKS370.26KERAXdCi11E3622001–
RENAULT TRUCKS370.26KERAXdCi11E3622001–
RENAULT TRUCKS370.26KERAXdCi11E3622001–2006
RENAULT TRUCKS370.26KERAXdCi11E3622001–
RENAULT TRUCKS370.32KERAXdCi11E3622001–
RENAULT TRUCKS370.32KERAXdCi11E3622001–
RENAULT TRUCKS370.32KERAXdCi11E3622001–
RENAULT TRUCKS385.18KERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.18/BKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.18TKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.18TKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.26KERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.26/A,385.26/BKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.26/A,385.26/B,385.26/CKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.26/BKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.26TKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.32/A,385.32/BKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.32/A,385.32/B,385.32/CKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS385.32/BKERAXMIDR06.23.56A/413811997–
RENAULT TRUCKS400.18KERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.18TKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.18TKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.26KERAXMIDR06.23.56B/413921998–2006
RENAULT TRUCKS400.26/A,400.26/B,400.26/CKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.26/BKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.26/BKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.26TKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.32/A,400.32/B,400.32/CKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS400.32/BKERAXMIDR06.23.56B/413922000–
RENAULT TRUCKS420.18KERAXdCi11C4122001–
RENAULT TRUCKS420.18KERAXdCi11C4122001–
RENAULT TRUCKS420.18KERAXdCi11C4122001–
RENAULT TRUCKS420.18KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.26KERAXdCi11C4122001–
RENAULT TRUCKS420.32KERAXdCi11C4122001–
RENAULT TRUCKS420.32KERAXdCi11C4122001–
RENAULT TRUCKS420.32KERAXdCi11C4122001–
RENAULT TRUCKS420.34KERAXdCi11C4122001–
RENAULT TRUCKSDistribution 210.16PREMIUMMIDR06.02.26W/42091996–
RENAULT TRUCKSDistribution 210.19DPREMIUMMIDR06.02.26W/42101996–
RENAULT TRUCKSDistribution 250.16PREMIUMMIDR06.02.26Y/412501996–
RENAULT TRUCKSDistribution 250.18DPREMIUMMIDR06.02.26Y/412501996–
RENAULT TRUCKSDistribution 250.19PREMIUMMIDR06.02.26Y/412501996–
RENAULT TRUCKSDistribution 260.16PREMIUMMIDR06.20.45C/42561996–
RENAULT TRUCKSDistribution 260.18PREMIUMMIDR06.20.45C/42561996–
RENAULT TRUCKSDistribution 260.19PREMIUMMIDR06.20.45C/42561996–
RENAULT TRUCKSDistribution 300.16DPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.16TPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.18DPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.18D/TPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.19PREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.19D/TPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.26DPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 300.26DPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSDistribution 320.18PREMIUMdCi11G3132000–
RENAULT TRUCKSDistribution 320.18 DPREMIUMdCi11G3132000–
RENAULT TRUCKSDistribution 320.24DPREMIUMdCi11G3132000–
RENAULT TRUCKSDistribution 320.26DPREMIUMdCi11G3132000–
RENAULT TRUCKSDistribution 340.18DPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 340.18D/TPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 340.19DPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 340.19D/TPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 340.26DPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 340.26DPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSDistribution 370.18PREMIUMdCi11E3622000–
RENAULT TRUCKSDistribution 370.18DPREMIUMdCi11E3622000–
RENAULT TRUCKSDistribution 370.24DPREMIUMdCi11E3622000–
RENAULT TRUCKSDistribution 370.26DPREMIUMdCi11E3622000–
RENAULT TRUCKSDistribution 400.18D/TPREMIUMMIDR06.23.56B/413922000–
RENAULT TRUCKSDistribution 420.18PREMIUMdCi11C4122000–
RENAULT TRUCKSDistribution 420.18DPREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 300.16PREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSRoute 300.18PREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSRoute 300.18TPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSRoute 300.19PREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSRoute 300.19TPREMIUMMIDR06.20.45D/412981996–
RENAULT TRUCKSRoute 320.18PREMIUMdCi11G3132000–
RENAULT TRUCKSRoute 320.18PREMIUMdCi11G3132000–
RENAULT TRUCKSRoute 340.18PREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 340.18TPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 340.19PREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 340.19TPREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 340.24PREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 340.26PREMIUMMIDR06.20.45E/413391996–
RENAULT TRUCKSRoute 370.18PREMIUMdCi11E3622000–
RENAULT TRUCKSRoute 370.18PREMIUMdCi11E3622000–
RENAULT TRUCKSRoute 370.24PREMIUMdCi11E3622000–
RENAULT TRUCKSRoute 370.26PREMIUMdCi11E3622000–
RENAULT TRUCKSRoute 385.18,400.18PREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.18,400.18PREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.18T,400.18TPREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.18T,400.18TPREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.19,400.19PREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.19,400.19PREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.19T,400.19TPREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.19T,400.19TPREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.24,400.24PREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.24,400.24PREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.24T,400.24TPREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.24T,400.24TPREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 385.26PREMIUMMIDR06.23.56A/413811996–
RENAULT TRUCKSRoute 385.26,400.26PREMIUMMIDR06.23.56B/41381-3921996–
RENAULT TRUCKSRoute 385.26,400.26PREMIUMMIDR06.23.56A/41381-3921996–
RENAULT TRUCKSRoute 420.18PREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 420.18TPREMIUMdCi11B/434122000–
RENAULT TRUCKSRoute 420.18TPREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 420.24PREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 420.24PREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 420.25PREMIUMdCi11C4122000–
RENAULT TRUCKSRoute 420.26PREMIUMdCi11C4122000–
