AS-PL S9570S Startmotor — EVINRUDE, JOHNSON

612,00 kr inkl. moms

STANDARD LINE | Tillverkare: AS-PL | Ersätter: JOHNSON ELECTRIC

Spänning [ V ] 12
Effekt [ kW ] 0.60
Startmotors rotation ACW
B-storlek [ mm ] 44.00
Antal kuggar [ qty. ] 9
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 208.00
O.1 [ mm ] 73.00
O.2 [ mm ] 81.00
O.3 [ mm ] 71.00
C.1 [ mm ] 9.50
C.2 [ mm ] 8.50
C.3 [ mm ] 9.50
AS-PLSTANDARD LINE
EAN5902129219170
ErsätterJOHNSON ELECTRIC

📄 Ladda ner datablad med skiss och mått (PDF)

SKU: S9570S Category: Tags: ,

Description

Denna produkt ersätter originaldelar från JOHNSON ELECTRIC.

Specifikationer

Spänning [ V ] 12
Effekt [ kW ] 0.60
Startmotors rotation ACW
B-storlek [ mm ] 44.00
Antal kuggar [ qty. ] 9
Antal hål i huvudet [ qty. ] 3
Antal gängade hål [ qty. ] 0
L.1 [ mm ] 208.00
O.1 [ mm ] 73.00
O.2 [ mm ] 81.00
O.3 [ mm ] 71.00
C.1 [ mm ] 9.50
C.2 [ mm ] 8.50
C.3 [ mm ] 9.50

Fordonskompatibilitet

MärkeModellTypMotorHkBränsleÅr
EVINRUDEE50DTL56.1ci-50H.P.01998–1998
EVINRUDEE50EL56.1ci-50H.P.01998–1998
EVINRUDEE50TTL56.1ci-50H.P.01998–1998
EVINRUDEE60EL49.7ci-60H.P.01986–1988
EVINRUDEE60EL56.1ci-60H.P.01998–1998
EVINRUDEE60TL49.7ci-60H.P.01986–1988
EVINRUDEE60TL56.1ci-60H.P.01998–1998
EVINRUDEE60TTL56.1ci-60H.P.01998–1998
EVINRUDEE6544.9ci-65H.P.01964–1979
EVINRUDEE65RWL49.7ci-65H.P.01985–1986
EVINRUDEE65TEL49.7ci-65H.P.01985–1986
EVINRUDEE65WML49.7ci-65H.P.01986–1988
EVINRUDEE65WML56.1ci-65H.P.01989–1989
EVINRUDEE70EL56.1ci-70H.P.01986–1997
EVINRUDEE70EL49.7ci-70H.P.01980–1985
EVINRUDEE70TL56.1ci-70H.P.01986–1997
EVINRUDEE70TL49.7ci-70H.P.01984–1985
EVINRUDEE70TTL56.1ci-70H.P.01991–1995
EVINRUDEE75E49.7ci-75H.P.01984–1988
EVINRUDEE75ER49.7ci-75H.P.01980–1983
EVINRUDEE75ERL49.7ci-75H.P.01980–1980
EVINRUDEE75TL49.7ci-75H.P.01984–1984
EVINRUDEE75TRL49.7ci-75H.P.01981–1983
JOHNSON40JPL Jet44.9ci-40H.P.01999–2001
JOHNSON50D56.1ci-50H.P.01998–1998
JOHNSON50TT56.1ci-50H.P.01998–1998
JOHNSON60EL49.7ci-60H.P.01986–1988
JOHNSON60PL56.1ci-60H.P.01999–2001
JOHNSON60TL56.1ci-60H.P.01998–1998
JOHNSON60TTL56.1ci-60H.P.01998–1998
JOHNSON6544.9ci-65H.P.01964–1979
JOHNSON65CWML49.7ci-65H.P.01987–1987
JOHNSON65RWL49.7ci-65H.P.01985–1986
JOHNSON65TEL49.7ci-65H.P.01985–1986
JOHNSON65W56.1ci-65H.P.01999–2001
JOHNSON70EL49.7ci-70H.P.01980–1985
JOHNSON70PL56.1ci-70H.P.01999–2001
JOHNSON70TL49.7ci-70H.P.01984–1985
JOHNSON70TL56.1ci-70H.P.01998–1998
JOHNSON70VL56.1ci-70H.P.02001–2001
JOHNSON75E49.7ci-75H.P.01980–1988
JOHNSON75ER49.7ci-75H.P.01983–1983
JOHNSON75ERL49.7ci-75H.P.01980–1980
JOHNSON75TL49.7ci-75H.P.01980–1984
JOHNSON75TRL49.7ci-75H.P.01983–1983
