S9061
Startmotorer
STANDARD LINE
1020 kr
Köp nu
| EAN | 5901259438000 |
| Tillverkare | AS-PL |
| Ersätter | MAGNETON |
| OE-nummer | 9142741 |
| Datablad | Ladda ner PDF med skiss och mått |
Specifikationer
| Spänning [ V ] | 12 |
| Effekt [ kW ] | 2.70 |
| Startmotors rotation | CW |
| A-storlek [ mm ] | 88.00 |
| B-storlek [ mm ] | 49.00 |
| Antal kuggar [ qty. ] | 10 |
| Antal kuggar (passar in) [ qty. ] | 10 |
| Antal hål i huvudet [ qty. ] | 3 |
| Antal gängade hål [ qty. ] | 0 |
| L.1 [ mm ] | 236.00 |
| O.1 [ mm ] | 90.00 |
| O.2 [ mm ] | 90.00 |
| O.3 [ mm ] | 127.00 |
| C.1 [ mm ] | 10.50 |
| C.2 [ mm ] | 10.50 |
| C.3 [ mm ] | 10.50 |
Passar i 56 fordon
| Märke | Modell | Typ | Motor | Hk | Bränsle | År |
|---|---|---|---|---|---|---|
| SISU | Engine | TD27DS4 | 0 | – | ||
| SISU | Engine | SISU411BS | 0 | – | ||
| SISU | Engine | TD33DS5 | 0 | – | ||
| SISU | Engine | SISU411C | 0 | – | ||
| SISU | Engine | SISU310B | 0 | – | ||
| SISU | Engine | TD44DS8 | 0 | – | ||
| SISU | Engine | TD27DS3 | 0 | – | ||
| SISU | Engine | SISU311C | 0 | – | ||
| SISU | Engine | TD33DS4 | 0 | – | ||
| SISU | Engine | SISU411B | 0 | – | ||
| SISU | Engine | TD33DS6 | 0 | – | ||
| SISU | Engine | SISU411 | 0 | – | ||
| SISU | Engine | SISU311CS | 0 | – | ||
| URSUS | C-330M | 0 | 1986–1993 | |||
| URSUS | C-335 | 0 | – | |||
| URSUS | C-360 | 0 | 1976–1992 | |||
| VALMET | 1100 | 0 | – | |||
| VALMET | 1102 | 411BS | 0 | – | ||
| VALMET | 1112 | 0 | – | |||
| VALMET | 1203 | 411CX | 0 | – | ||
| VALMET | 305 | TD27DS3 | 0 | – | ||
| VALMET | 405 | TD27DS4 | 0 | – | ||
| VALMET | 455 | TD33DS4 | 0 | – | ||
| VALMET | 500 | 310B | 0 | 1969–1975 | ||
| VALMET | 502 | 310B | 0 | 1969–1975 | ||
| VALMET | 504 | D27B | 0 | – | ||
| VALMET | 505 | TD33DS5 | 0 | – | ||
| VALMET | 542 | 310B | 0 | 1969–1975 | ||
| VALMET | 6000 | 0 | 1990– | |||
| VALMET | 602 | 311C/311CS | 0 | – | ||
| VALMET | 604 | D33C/TD33C | 0 | – | ||
| VALMET | 605 | TD33DS6 | 0 | – | ||
| VALMET | 655 | D44D7 | 0 | – | ||
| VALMET | 6600 | 0 | 1990– | |||
| VALMET | 700 | 0 | 1971–1972 | |||
| VALMET | 702S | 411B/411BS | 0 | – | ||
| VALMET | 703 | 411C | 0 | – | ||
| VALMET | 705 | TD44DS7 | 0 | – | ||
| VALMET | 712 | 0 | 1971–1972 | |||
| VALMET | 755 | TD | 0 | – | ||
| VALMET | 802 | 411CS | 0 | – | ||
| VALMET | 803 | 411CS | 0 | – | ||
| VALMET | 805 | TD44DS8 | 0 | – | ||
| VALMET | 855 | TD44DS8 | 0 | – | ||
| VALMET | 900 | 0 | 1969– | |||
| VALMET | 903 | 411CS9 | 0 | – | ||
| ZETOR | 3320 | Major | Z5201 | 45 | 1992–2006 | |
| ZETOR | 3340 | Major | Z5201 | 45 | 1992–2006 | |
| ZETOR | 4320 | Major | Z6201 | 57 | 1992–2006 | |
| ZETOR | 4340 | Major | Z6201 | 57 | 1992–2006 | |
| ZETOR | 5320 | Major | Z7201 | 63 | 1992–2006 | |
| ZETOR | 5340 | Major | Z7201 | 63 | 1992–2006 | |
| ZETOR | 6320, 7320 | Major | Z7301 | 68-78 | 1992–2006 | |
| ZETOR | 6320, 7320 | Major | Z7701 | 68-78 | 1992–2006 | |
| ZETOR | 6340, 7340 | Major | Z7701 | 68-78 | 1992–2006 | |
| ZETOR | 6340, 7340 | Major | Z7301 | 68-78 | 1992–2006 |
